Servo can be upgraded to 2K FW. Please state when you order if you want us to do this upgrade. 2K FW will increase the servo update frequency from 1khz to 2khz in Xbus mode.
Stall Torque:
37.6 kgs (4.8V) / 51.7kgs (6.6V) / 58.0kgs (7.4V) / 65.8kgs (8.4V)kg・cm
Speed:
0.20 (4.8V)/0.15 (6.6V)/0.13 (7.4V)/0.11 (8.4V) Sec/60°
Weight: 79 g
Dimension: 35 x 20 x 40.5 mm
Length of lead harness: 300mm
Operating Voltage: 4.5V - 8.5V
■Programmable
■Super steel full metal gear(Gear B brass)
■BIG upper ball bearing (12x6) bottom(10x6)
■Special design Brushless motor
Best setting for super light Airplanes
Ex .3D airplanes IMAC airplanes . Jets and composite small control surface:
Holding +5
Dumping +20
Dead band 0
Boost +100 to 200
